Circuit protection devices protect people, equipment and wiring from overloads, short circuits and faults. Choosing the right device is critical for safety and code compliance.
Circuit Protection Products
Fuses provide fast, dependable overcurrent protection for circuits, motors, drives and electronics. Their high interrupting ratings make them ideal where fault currents are high.
Fuse Types
- Class CC, J and RK fuses – branch circuit protection
- Time-delay fuses – motor inrush tolerance
- Fast-acting fuses – electronics protection
- Semiconductor fuses – drives and rectifiers
- Midget and glass fuses – control circuits
Choosing a Fuse
Match class, amperage, voltage and interrupting rating to the circuit and fuse holder. Use time-delay fuses for motors and fast-acting fuses for semiconductors.
Centro carries fuses for industrial and commercial electrical systems.
Related categories: Circuit Protection | Fuse Blocks and Holders | Circuit Breakers | Disconnect Switches | Breaker Conversion Kits
Fuse blocks and holders mount fuses securely and safely in panels and equipment. Finger-safe designs and indicators make maintenance safer and quicker.
Fuse Block Types
- DIN rail fuse holders – compact control panel mounting
- Panel-mount fuse blocks – power distribution
- Finger-safe holders – reduce shock hazards
- Indicating holders – show blown fuses
- Inline holders – wire-mounted protection
Choosing a Holder
Match fuse class, size, amperage, voltage and number of poles. Check UL ratings and wire range. Indicating holders cut troubleshooting time.
Centro supplies fuse blocks and holders for control panels.
Related categories: Circuit Protection | Disconnect Switches | Fuses | Circuit Monitoring | Circuit Breakers
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
Subject to factory lead times
- Circuit protection refers to devices — circuit breakers, fuses, and disconnect switches — that guard electrical equipment, wiring, and personnel by interrupting current flow when a fault occurs. Overcurrents caused by short circuits, ground faults, or sustained overloads generate excessive heat that can damage insulation, melt conductors, and start fires. Circuit protection devices detect these conditions and open the circuit before damage occurs. In industrial settings, properly specified circuit protection is not optional — it is required by the National Electrical Code (NEC) and ensures that a fault in one branch circuit does not cascade into a facility-wide failure.
- Both fuses and circuit breakers interrupt current flow during an overcurrent event, but they differ in operation and reusability. A fuse contains a metal element that melts and permanently opens the circuit when current exceeds its rating — it must be replaced after each event. A circuit breaker uses a mechanical or electromechanical mechanism to trip and open the circuit, and it can be reset and reused after the fault is cleared. Fuses offer faster response times and are simpler and less expensive for individual circuit protection. Circuit breakers are more practical where frequent tripping may occur, where resettability reduces downtime, or where remote or adjustable trip settings are needed. In many industrial panels, both are used — fuses for high-speed protection of sensitive components and circuit breakers for branch circuit and feeder protection.
- A molded case circuit breaker (MCCB) is a heavy-duty circuit breaker housed in a rigid, insulated molded case. MCCBs are designed for higher current ratings — typically from 15 amps up to 2,500 amps — making them the standard choice for protecting feeders, branch circuits, and large motor loads in industrial and commercial distribution panels. They provide both thermal protection against sustained overloads and magnetic protection against short circuits. Many MCCBs offer adjustable trip settings, allowing the trip current and delay to be tuned to match the specific load characteristics. For applications requiring coordination between upstream and downstream protective devices, MCCBs provide selectable trip curves that prevent nuisance tripping while ensuring the nearest device to the fault clears first.
- A disconnect switch is a manually operated device that provides a visible, lockable means of isolating a circuit or piece of equipment from its power source. Its primary purpose is safety — it allows maintenance personnel to de-energize equipment and lock it in the off position (lockout/tagout per OSHA standards) so work can be performed without risk of accidental energization. Disconnect switches do not typically provide overcurrent protection on their own; they are paired with fuses (creating a fused disconnect) or installed alongside circuit breakers. Fused disconnects combine isolation and overcurrent protection in a single enclosure, reducing panel space and simplifying wiring. Disconnect switches are required by code at the service entrance, at motors, and at most equipment that requires periodic maintenance access.
- The rating of a fuse or breaker must match the wire size and the load it protects — not the equipment's maximum draw alone. Start with the full-load current of the equipment, then apply NEC derating factors for continuous loads (typically 125% of continuous current). Select a fuse or breaker whose ampere rating does not exceed the ampacity of the conductor it protects. For motor circuits, the NEC specifies separate rules — the branch circuit protective device is sized based on motor full-load current tables (not nameplate), and the type of fuse or breaker (time-delay fuse, inverse-time breaker, instantaneous-trip breaker) determines the maximum allowed percentage. Undersizing causes nuisance tripping; oversizing defeats the purpose of protection and can allow wiring to overheat before the device trips. When in doubt, consult the NEC tables or contact a product expert for proper coordination.
- Circuit breaker accessories extend the functionality of the breaker beyond basic overcurrent protection. Common accessories include shunt trips (allow remote tripping from an external signal or emergency stop), auxiliary contacts (provide status feedback to a PLC or alarm system indicating whether the breaker is open or closed), undervoltage releases (trip the breaker if supply voltage drops below a safe level), and handle locks (lock the breaker in the on or off position for safety compliance). Circuit breaker enclosures are protective housings that mount around the breaker, shielding it from dust, moisture, and accidental contact. Enclosures are rated by NEMA or IP standards — NEMA 1 for general indoor use, NEMA 4/4X for washdown or outdoor environments. Selecting the right enclosure ensures the breaker operates reliably in its installed environment and meets workplace safety requirements.
