Turbine Flow Meters - ICON

The ProPulse®2 provides superior performance and delivers accurate Ultra-Low Flow measurement that is highly repeatable under the most demanding of industrial environments. The ProPulse®2 operates using a PVDF rotor with encapsulated magnetic inserts, which rotate on a long-wearing set of sapphire bearings designed to provide years of reliability. As the rotor spins, the magnetic field produced by the magnets is picked up via a Hall Effect Sensor, which converts the rotation into a square wave NPN pulse, 4 – 20mA, or RS485 output that can be sent directly to a metering pump or local display.

The TKB Series battery operated in-line plastic paddle wheel flow meter sensor has been designed for tough industrial applications. The TKB series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement for both corrosive and non-corrosive liquids. The all plastic in-line digital flow meter sensor is equipped with a 360° rotatable vivid backlit LCD display showing both Flow Rate & Flow Total. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry’s most accurate flow meter sensor. The TKB series plastic flow meter sensors incorporate an all new re-designed air-foil designed rotor that reduces turbulence and drag as the liquid passes by up to 92%. The zirconium rotor pin has been polished to a mirror finish and provides superior chemical and wear resistance over a metal pin. It should be noted that the rotor has been outfitted with two (2) ceramic bushings. This allows for much finer rotor pin to paddle alignment and greatly reduces paddle wobble that occurs without bushings. Icon’s liquid flow meters incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TKB series battery operated liquid flow meter is industry’s longest lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly.

The TKP Series digital in-line paddle wheel flow meter sensor has been designed for tough industrial applications. The TKP series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement for both corrosive and non-corrosive liquids. The plastic in-line flow meter sensor is equipped with a 360° rotatable vivid LED display showing both Flow Rate & Flow Total and provides a frequency pulse output. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry’s most accurate flow meter sensor. The TKP series plastic flow meter sensors incorporate an all new re-designed air-foil designed rotor that reduces turbulence and drag as the liquid passes by up to 92%. The zirconium rotor pin has been polished to a mirror finish and provides superior chemical and wear resistance over a metal pin. It should be noted that the rotor has been outfitted with two (2) ceramic bushings. This allows for much finer rotor pin to paddle alignment and greatly reduces paddle wobble that occurs without bushings. Icon’s liquid flow meters incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TKP series liquid flow meter is industry’s longest lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly.

The TK3M Series stainless steel digital paddle wheel flow meter sensor has been designed for tough industrial applications. The TK3M series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement of liquids. The 316SS in-line flow meter sensor is equipped with a 360° rotatable vivid LED display showing both Flow Rate & Flow Total and provides a 4-20mA output. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry’s most accurate flow meter. The TK3M series flow meter sensors incorporate an all new re-designed air-foil designed rotor that reduces turbulence and drag as the liquid passes by up to 92%. The zirconium rotor pin has been polished to a mirror finish and provides superior chemical and wear resistance over a metal pin. It should be noted that the rotor has been outfitted with two (2) ceramic bushings. This allows for much finer rotor pin to paddle alignment and greatly reduces paddle wobble that occurs without bushings. Icon’s liquid flow meters incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TK3M series liquid flow meter is industry’s longest lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly.

Icon Process Controls’ Truflo® TI Series Insertion Paddle Wheel Flow Meters combine precision, durability, and advanced technology to meet a range of industrial needs. These flow meters deliver accuracy of ±0.5% and are constructed from durable, chemical-resistant materials like PVC, PP, and PVDF, ensuring reliability in challenging environments. Icon Process Controls also offers the TI3B Paddle Wheel Flow Meter – a 316 SS option! The TIB digital flow meter sensors are easy to install with exceptional guaranteed long-life performance and have been engineered to provide long-term accurate flow measurement in tough industrial applications. The battery-operated plastic insertion flow meter sensor is equipped with an optional 330° rotatable vivid LCD display showing both Flow Rate & Flow Total. The paddle wheel assembly consists of an engineered high performance Tefzel® paddle and micro-polished zirconium ceramic rotor pin and bushings, providing excellent chemical and wear resistant properties. The TIB Series paddle wheel flow meter sensors are highly repeatable, exceptionally accurate, extremely rugged, offer outstanding value and require absolutely no maintenance. The TIB flow meter sensors can be installed using Truflo’s® extensive line of ANSI and DIN fittings. Truflo® offers SDR Pipe Saddles from DN15 – DN600 in GFPP material.

Icon Process Controls’ Truflo® TIF Insertion Paddle Wheel Flow Meter seamlessly combines precision, durability, and advanced technology to meet a wide range of industrial needs. These flow meters deliver accuracy of ±0.5% and are constructed from durable, chemical-resistant materials like PVC, PP, and PVDF, ensuring reliability in challenging environments. Icon Process Controls also offers the TI3F Paddle Wheel Flow Meter – a 316 SS option! The TIF Series has been engineered to provide long-term accurate flow measurement for both corrosive and non-corrosive liquids. The insertion paddle wheel flow meter provides a 2x Relay (10A) output and is equipped with an optional 330° rotatable vivid LED display showing Flow Rate + Flow Total + Batching. The re-engineered low-drag, fluid-dynamic design of the chemical paddle wheel allows it to stand alone as the industry’s most accurate flow meter sensor. Icon’s paddle wheel flow meter sensors incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TIF liquid flow meter sensor is industry’s longest lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly. The digital flow meter sensors can be installed into pipe sizes ½ – 24” using our line of comprehensive custom fittings. Icon’s complete line of insertion paddle wheel flow meter sensors will also retrofit into any Signet® style fitting.

The TK3B Series stainless steel battery-operated paddle wheel flow meter sensor has been designed for tough industrial applications. The TK3B series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement for liquids. The 316SS in-line flow meter sensor is equipped with a 360° rotatable vivid backlit LCD display showing both Flow Rate & Flow Total. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry’s most accurate flow meter sensor. The TK3B series flow meter sensors incorporate an all new re-designed air-foil designed rotor that reduces turbulence and drag as the liquid passes by up to 92%. The zirconium rotor pin has been polished to a mirror finish and provides superior chemical and wear resistance over a metal pin. It should be noted that the rotor has been outfitted with two (2) ceramic bushings. This allows for much finer rotor pin to paddle alignment and greatly reduces paddle wobble that occurs without bushings. Icon’s liquid flow meters incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TK3B series liquid flow meter is industry’s longest lasting paddle wheel flow meter and comes with a lifetime warranty on the paddle wheel assembly.

Icon Process Controls’ Truflo® TIM Insertion Paddle Wheel Flow Meter seamlessly combines precision, durability, and advanced technology to meet a wide range of industrial needs. These flow meters deliver accuracy of ±0.5% and are constructed from durable, chemical-resistant materials like PVC, PP, and PVDF, ensuring reliability in challenging environments. Icon Process Controls also offers the TI3M Paddle Wheel Flow Meter – a 316 SS option! The TIM Series digital paddle wheel flow meter sensor has been designed for tough industrial applications. The TIM series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement for both corrosive and non-corrosive liquids. The plastic insertion flow meter sensor is equipped with an optional 330° rotatable vivid LED display showing both Flow Rate & Flow Total and provides a frequency pulse | 4-20mA or optional Voltage output. The re-engineered low-drag, fluid-dynamic design of the paddle wheel allows it to stand alone as the industry’s most accurate chemical flow meter. Icon’s paddle wheel flow meter sensors incorporate a Tefzel® paddle coupled with a zirconium ceramic rotor pin and bushings. The TIM series liquid flow meter sensor is the industry’s longest lasting plastic flow meter sensor and comes with a lifetime warranty on the paddle wheel assembly. The flow meter sensors can be installed into pipe sizes ½ – 24” using our line of comprehensive custom fittings. Icon’s complete line of insertion paddle wheel chemical flow meter sensors will also retrofit into any Signet® style fitting.

Icon Process Controls’ Truflo® TIP Insertion Paddle Wheel Flow Meter seamlessly combines precision, durability, and advanced technology to meet a wide range of industrial needs. These flow meters deliver accuracy of ±0.5% and are constructed from durable, chemical-resistant materials like PVC, PP, and PVDF, ensuring reliability in challenging environments. Icon Process Controls also offers the TI3P Paddle Wheel Flow Meter – a 316 SS option! The TIP Series paddle wheel flow meter sensor has been engineered to provide long-term accurate flow measurement for both corrosive and non-corrosive liquids. The plastic insertion flow meter sensor provides a frequency pulse or an RS485 optional output, and is equipped with an optional 330° rotatable vivid LED display showing both Flow Rate & Flow Total. The paddle wheel assembly consists of an engineered high performance Tefzel® paddle and micro-polished zirconium ceramic rotor pin and bushings, providing excellent chemical and wear resistant properties. The TIP Series paddle wheel flow meter sensors are highly repeatable, exceptionally accurate, extremely rugged, offer outstanding value and require absolutely no maintenance. The TIP flow meter sensors can be installed using Truflo’s® extensive line of ANSI and DIN fittings. Truflo® offers SDR Pipe Saddles from DN15 – DN600 in GFPP material.
